| ● Basic Parameters | |
| Types | Passive RFID tag |
| Working Frequency | 13.56MHz, 860-960MHz |
| Protocol | ISO14443A, ISO / IEC 18000-6C EPC Class1 Gen2 |
| ● Physical Parameters | |
| Size | 448 * 28 * 8mm (can be customized) |
| Packaging Materials | PP + nylon |
| Antenna | Aluminum etching antenna |
| Craft | Silk screen print,Inkjet print,Encoding |
| ● Performance parameters | |
| Chip | S50 / S70, Ultralight EV1 / Ultralight C, NTAG213 / 216, I CODE SLIX, FM1108, Alien H3, impinjM4D / M4E / M4QT / M5 |
| Storage | Related to the chip |
| Operating mode | read and write |
| Data Retention | > 10 years |
| Write Endurance | 100,000 times |
| Reading distance | 0-15m (Related to the chip,antenna and JINYINGUHF Readers) |
| Enviromental parameters | |
| Operating temperature | (-25 ℃ ~ + 55 ℃) |
| Storage temperature | (-35 ℃ ~ + 75 ℃) |
| ● Typical applications | |
| Applications | Supply chain management,Food tracking,Asset management |
| ● Package | |
| Packaging Information | 50pcs / bundle |
