| Product Parameter | Parameter Description |
| JINYINGModel | JINYING-505BW |
| Product Name | Wireless Large Non-touch Switch |
| Wireless Receiver | |
| Power supply | AC/DC 12-30V |
| Static current | 34mA (DC 12V power) |
| Action current | 62mA (DC 12V power) |
| Relay connect capacity | 1A DC24V |
| Connect holding time | 1.5 seconds |
| Dimension | 110(L)x30(W)x15(H)mm |
| Wireless Transmitter | |
| Power supply | 3V(2pcs 1.5V AA batteries) |
| Standby current | ≤80μA |
| Transmitting current | 10mA |
| Batteries life | 200 times everyday, about 450 days |
| Receiver sensitivity | -95dbm |
| Sensing distance | 0-30 cm |
| Launch distance | about 30 meters |
| Dimension | 115(L)x115(W)x20(H)mm |
