Model:
EL-600SZBrand:
JINYING| Model No. | LED | Lock Sensor | Door Sensor | Time Delay | Buzzer | Voltage | |
| EL-600 | X | X | X | X | X | 12V | |
| EL-600SD | √ | √ | X | X | X | 12V & 24V | |
| EL-600ST | √ | √ | X | √ | X | 12V & 24V | |
| EL-600SZ | √ | √ | X | X | √ | 12V & 24V | |
| EL-600LSD | √ | √ | √ | X | X | 12V & 24V | |
| Product Parameter | Parameter Description | ||||||
| Product Name | Single Door 600LBS Magnetic Lock | ||||||
| Size | 250Lx48.5Wx25H(mm) | ||||||
| Armature Plate Dimension | 180Lx38Wx11H(mm) | ||||||
| Holding Force | 280KG(600LBS) | ||||||
| Input Voltage | DC12V (Adjustable DC24V) | ||||||
| Current | 12V/500mA(±10%) ; 24V/250mA(±10%) | ||||||
| Suitable | Wooden door , Glass door ,Metal door , Fireproof door | ||||||
| Surface Temp | ≤+20℃ | ||||||
| Operating Temp | -20℃~+55℃(-4—131°F) | ||||||
| Humidity | 0~90%(non-condensing) | ||||||
| Weight | 1.8KG | ||||||
| Standard Package | 10PCS/CTS | ||||||
| Carton Weight | 18KG | ||||||
| Carton Size | 35*30*18 (cm) | ||||||
