| Product Parameter | Parameter Description |
| JINYINGModel | ES-150 |
| Product Name | European Narrow-type and Adjustable Electric Strike lock |
| ES-150 | Fail-safe and Fail-secure adjustable |
| Lock Size | 110Lx25Wx31.5H(mm) |
| Strike Structure | Zinc die-casting |
| Holding Stength | 600kg |
| Voltage | DC12V |
| Current | 700mA |
| Special Disign | Adjust Lock-tongue to NO style |
| Surface Temperature | Within +20°C |
| Suitable Temperature | -10~+25°C(14-131F) |
| Face plate Housing | Surface by coating nickel |
| Surface by | Coating nickel and polishing |
| Funtion | Built-out MOV |
| Suitable For | Narrow Wooden Door,Narrow Metal Door |
| Opening Mode | 90 Degree Swinging Door |
| Unit Weight | 0.38KG |
| Standard Package | 30PCS |
| Carton Weight | 11.5KG |
| Carton Size | 55*31*21 (cm) |
