Model:
JINYING-12V 8ABrand:
JINYING| Product Parameter | Parameter Description |
| JINYINGModel | JINYING-12V 8A |
| Product Name | Wide Voltage Switching Power Supply |
| Input voltage | AC220V |
| Input frequency | 50Hz |
| The output voltage | DC12V |
| Output current | 8A |
| Output voltage fine-tuning range | 10% sword~15% sword |
| Load stability | 1% typical |
| Output stability | 0.5% typical |
| Ripple and noise | 1%, peak-to-peak value (100mVp-p typical value) |
| Insulation withstand voltage | 1500VAC between primary and secondary poles, 1500VAC between primary and shell, 500VAC between secondary shells |
| Hold time | Typical value is 20ms at full load |
| Working temperature | -20℃~65℃ |
| Overload protection | All the output terminals are short-circuited or overloaded, the electric lock is protected and the output delay is 0~30 seconds |
| Dimension | 128x51x36mm |
| Weight | 105g |
