Model:
JINYING-R2430Brand:
JINYING| Product Parameter | Parameter Descr1ption |
| JINYINGModel | JINYING-R2430 |
| Product Name | 2.45G Omni-Directional Active RFID Reader |
| Working frequency | 2.4G ISM (2402~2483MHz) |
| Size | 230.6*164*72mm |
| Weight | 1.2kg |
| Material | Die-cast aluminum |
| RFID RF communication standard | Meet ISO18000-4-2015 |
| Operating mode | Transceiver |
| Mobile recognition speed | 200km/h |
| IP protection level | IP67 |
| Wired tag reader communication interface | RS232/RS485 |
| Communication method | RS232/RS485/Ethernet/4G-LTE/2.4G-WiFi |
| 2.4G RFID antenna interface | 50ohm N-type(Female) |
| 4G-LTE antenna interface | 50ohm N-type(Female) |
| GNSS antenna interface | 50ohm N-type(Female) |
| 2.4G WiFi antenna interface | 50ohm N-type(Female) |
| Power supply interface | DC 5.0V/3A |
| Max power consumption of the whole machine | 2W (4G tag reader mode) |
| Operating temperature | -40°~+85° |
| Storage temperature | -40°~+125° |
| Secondary development resources | Provide DEMO and C#, C++, Java SDK |
